Dynam 4.0mm Dia 90 Degree Metal E-Retract Landing Gear V3

Dynam 4.0mm Dia 90 Degree Metal E-Retract Landing Gear V3 – DY-1150

Dynam new upgraded metal E-Retract retractable landing gear! Engineered for high torque, realistic scale-speed performance, and unparalleled durability.

• Rigorously tested for reliability and stability, rest assured our landing gear delivers continuous and dependable performance under all conditions.
• Sensor-Free, Chip-Controlled: Dynam E-Retract now boasts advanced chip control technology, making operation smoother and more hassle-free than ever before.
• Enhanced Efficiency: Thanks to a redesigned internal structure, the motors within our landing gear operate with enhanced efficiency.

Operating Conditions:

Temperature: -20℃ to 60℃ / -4℉ to 140℉
Humidity: 15% to 90% RH (no condensation)

Storage Conditions:

Temperature: -20℃ to 70℃ / -4℉ to 158℉
Humidity: 15% to 75% RH (no condensation)

This retractable landing gear is suitable for model airplanes with a wingspan of 1000mm to 1800mm.

Features

• Robust landing gear strut and mounting bracket.

• Integrated electric motor.

• Built-in overcurrent protection.

• For aircraft weight: 1-4.0 kg.

Specifications

Speed: 1.25sec @4.8v, 1.00sec @6.0v, 0.8sec @7.4v
Weight: 39.5g
Torque: 3.5kg.cm
Motor type: electric brushed
Gear: metal
Current draw idle: 5mA
Current draw stall: 200mA
Voltage: 4.8v-7.4v
Retract degree: 90°
Hole diameter: Ø4.0mm
